| Expansion |
Slots |
PCIe x16 |
| Form Factor |
Form Factor |
mini ITX |
| Processor |
CPU |
Intel Core 2 Duo T9400 / P8600 / P8400 / Intel Celeron M 575 |
| CPU TDP |
35 / 25 /31 W |
| Frequency |
2.53 / 2.4 / 2.26 / 2.0 GHz |
| Core Number |
2002-2-1 |
| L2 Cache |
6 / 3/ 1 / 1 MB |
| BIOS |
Award SPI 16 Mbit |
| Chipset |
Intel GM45, ICH9M |
| Memory |
Technology |
DDR3 800 / 1066 MHz |
| Max. Capacity |
4 GB |
| Socket |
2 x 204-pin SODIMM |
| Display |
Controller |
Intel GM45 GMCH integrated |
| Graphic Memory |
Share with system memory up to 384 MB |
| LCD (TTL/LVDS/eDP) |
LVDS: Single channel 18 / 24-bit/Dual channel 36/48-bit |
| DDI (HDMI/DVI/DisplayPort) |
DVI |
| Multiple Display |
Dual |
| Expansion |
PCI Express x 16 |
1 |
| Ethernet |
Controller |
GbE1: Realtek RTL8111C; GbE2: Realtek RTL8111C |
| Speed |
10/ 100/ 1000 Mbps |
| Connector |
RJ45 x 2 |
| Audio |
Audio Interface |
HD Audio |
| CODEC |
Realtek ALC888, High Definition Audio (HD) |
| Connector |
3 (Mic-in, Line-in, Line-out) |
| Watchdog Timer |
WatchDog Timer |
Yes |
| Storage |
SATA |
2 x SATA II (Max. Data Transfer Rate 300 MB/s) |
| CompactFlash |
CompactFlash Type I/II (Primary Master IDE Channel) |
| I/O |
USB2.0 |
8 |
| GPIO |
1 |
| COM Port |
4 (RS-232) |
| Keypad |
2 |
| Power |
Power Type |
ATX, AT |
| Connector |
ATX20P |
| Environment |
Operational Temperature |
0 ~ 60° C (32 ~ 140° F) |
| Non-Operational Temperature |
-20~ 70° C |
| Vibration Resistance |
3.5 Grms (non OP) |
| Physical |
Dimension (mm) |
170x 170 mm (without heatsink) |
| Weight |
1.04 kg (1.72 lb), weight of total package |
| Construction |
with CPU cooler design |
| Operating System |
Microsoft Windows |
Yes |
| Linux |
Yes |
| SUSIAccess |
Yes |
| Certification |
EMC |
CE, FCC |
