| TPC-1581WP-433AE |
| Environment |
Humidity |
10 ~ 95% RH @ 40°C, non-condensing |
| Ingress Protection |
Front panel: IP66 |
| Operating Temperature |
0 ~ 55°C (32 ~ 131°F) |
| Storage Temperature |
-20 ~ 60° C (-4 ~ 140° F) |
| Vibration Protection |
With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration) |
| General |
BIOS |
AMI UEFI |
| Certifications |
BSMI, CCC, CE, FCC Class A, UL |
| Cooling System |
Fanless design |
| Dimensions (W x H x D) |
419.7 x 269 x 56.7 mm (16.52" x 10.59" 2.23") |
| Enclosure |
Front bezel: Die-cast Aluminum alloy, Back housing: PC/ABS Resin |
| Mounting |
Panel Mount |
| OS Support |
Microsoft® Windows WES7 32bit/64bit /WES8 64bit /Windows 7 32bit/64bit / Windows 8 64bit Linux Kernel 3.x |
| Power Consumption |
18W Typical, 60W Max. (Without Add-on card) |
| Power Input |
24VDC +/- 20% |
| Watchdog Timer |
1 ~ 255 sec (system) |
| Weight (Net) |
6.0 kg (13.2 lbs) |
| LCD Display |
Backlight Life |
50,000 hrs |
| Contrast Ratio |
500:01:00 |
| Display Size |
15.6" |
| Display Type |
WXGA TFT LED LCD |
| Luminance (cd/m2) |
300 |
| Max. Colors |
16.7M |
| Max. Resolution |
1366 x 768 |
| Viewing Angle (H/V°) |
170/160 |
| System Hardware |
Chipset |
Lynx Point-LP |
| CPU |
Intel 4th Generation Core i3-4010U 1.7GHz |
| Expansion Slots |
Full-sized Mini PCI-E x 1 |
| I/O |
RS-232 x1, RS-232/422/485 x 1, USB 2.0 x 2 (Host) |
| LAN |
10/100/1000Base-T x 2 |
| Memory |
4GB DDR3L 1600MHz SO-DIMM SDRAM |
| Touchscreen |
Light Transmission |
≥88% |
| Resolution |
2048 x 2048 |
| Type |
Projected capacitive |
