| General |
Power Consumption |
40 W (Typical, no add-on card) |
| Mounting |
Wallmount, Stand, Panel |
| Certifications |
CE, FCC class A, UL, CCC |
| Weight |
4.5 kg |
| Dimensions |
157 x 238 x 177mm (6.2”x 9.3”x 7”) |
| Enclosure Housing |
Aluminum + SECC |
| OS Support |
WES2009, Windows Vista/XP, Windows 7, Linux, QNX |
| Industrial Grounding |
Isolation between chassis and power ground |
| Power Requirement |
9 ~ 36VDC (e.g +24V @ 5A), ATX, AT/ATX power Jumper selection and BIOX AT simulation |
| System Design |
Fanless with no internal cabling |
| Remote Management |
Built-in Advantech DiagAnywhere agent on Windows CE/XPe |
| System Hardware |
CPU |
Intel Core 2 Duo L7500 1.6 GHz |
| Memory |
4 GB DDR3 SDRAM built-in |
| Expansion Slots |
2 x PCI |
| Audio |
AC 97, Line Out |
| Display |
Dual DVI-D independent, or DVI-D + Dual VGA cloned displays |
| Processor System |
Watchdog Timer |
Programmable 256 levels timer interval, from 1 to 255 sec |
| System Hardware |
Indicators |
LEDs for Power, Standby, HDD, SRAM battery, Rx/Tx for COM ports |
| Battery Backup Memory |
512 KB |
| Timer/Counter |
Counter Source |
DI1 & DI3 |
| Pulse Output |
DO2 & DO3 |
| Time Base |
100 kHz, 10 kHz, 1 kHz, 100 Hz |
| I/O Interface |
Serial Ports |
2 × RS-232/422/485 with DB9 connectors, automatic RS-485 data flow control, 2 x RS-232 (optional) |
| USB |
5 x USB 2.0 (one internal), 2 x USB 2.0 pin header |
| LAN |
2 x 10/100/1000 Base-T RJ-45 ports |
| Communication Speed |
RS-232 Speed: 50 bps ~ 115.2 kbps, RS-422/485 Speed: 300 bps ~ 921.6 kbps (Max) |
| IEEE 1394 (Firewire) |
2 x type B (Bilingual) |
| Environment |
Temperature (Operating) |
-10 ~ 55° C (14 ~ 131° F) |
| Temperature (Storage) |
-20 ~ 80° C (-4 ~ 176° F) |
| Humidity (Operating) |
95% @ 40° C (non-condensing) |
